Description
ICON Vehicle Dynamics V.S. 2.5 Series remote reservoir front coilover shocks are an incredible upgrade for the front end of the 2005-2023 Toyota Tacoma. These adjustable coilovers allow up to 0-3.5” of lift height adjustability on 2005-2015 models or 0-2.75” of lift height adjustability on 2016-2023 modelsallowing the use of largermore aggressive wheel and tire combinations. ICON’s Vehicle-specific shock length and valving along with the larger 2.5” shock body and increased piston area over stock components yield the maximum travel possible along with superior ride quality and suspension performance both on- and off-road. Remote reservoirs greatly increase shock oil volume and heat dissipation surface area to resist overheating and cavitation under hard usewhich can lead to damper fade. To better support the weight of additional accessories such as aftermarket front bumpers and winchesthese coilovers include ICON engineered coil springs with an increased700 lbs/in spring rateallowing for taller ride heights with increased front end weight. When paired with ICON 2.0 or 2.5 Aluminum Series rear shock absorbers vehicle control will be balanced front to rearresulting in the best overall driving experience for your Toyota Tacoma.
Features
- Height-adjustable coilovers offer 0-3.5″ or 0-2.75″ of lift height adjustment depending on year model
- External Reservoirs Ensures Maximum Cooling
- ICON engineered coil springs with 700 lbs/in spring rate are more ideal for heavier equipped front ends
- Vehicle specific tuned for superior shock damping and control
- Kit Includes Sway bar relocation brackets
- Kit also Includes Reservoir Mounting Brackets for Optimum Tire Clearance
- CAD-plated threaded body
- Billet aluminum upper mount
- 5/8″ PTFE-lined spherical bearings
- Completely re-buildable
- Hose Length Optimized for Increased Fluid Transfer
- Oem wheels & tires fitment: yes; tech note: 700lb/in spring rate only recommended for trucks with additional weight added to front end.
- See icon help center for information.
- ; tech note: will not fit 2005-2015 2wd 5-lug toyota tacoma models; tech note: 2005-2015 toyota tacoma will have front lift height range of 0-3.
- 5″ over stock; tech note: 2017-2023 tacoma trd pro models will have front lift height range of 0-1.
- 25″ over stock; recommended aftermarket wheels: icon alloys – 17×8.
- 5 with 4.
- 75” backspace / 0mm offset; recommended aftermarket wheels: icon alloys – 18×9 with 5.
- 00” backspace / 0mm offset; recommended aftermarket wheels: icon alloys – 20×9 with 5.
- 00” backspace / 0mm offset; recommended aftermarket tires: 33″ x 11.
- 50″ (larger tires may fit but fender trimming and modifications will be required.
- ); application note #55: shocks are fully serviceable.
- Coilover heights indicated are for a stock equipped vehicle; application note #109: 2016-2023 tacoma lift range is 0-2.
- 75”; application note #110: trimming required for recommended tire size; application note #111: bump stop spacer kit 51045 can be installed to increase preload .
- 25” beyond maximum
Quick SpecsOverview:
- Spring Rate: 700 PPI
- Spring Material: Steel
- Adjustable Height: yes
- Grade Type: Performance
- Shock Absorber Rod End Measuring Point: Center of Eylet
- Shock Absorber Body End Measuring Point: Top of Upper Mount Plate
- Lower Mount Type: Eyelet
- Upper Mount Type: Mounting Plate
- Boot Included: No
- Gas Charged: yes
- Body Diameter: 2.5 IN
- Dust Shield Included: No
- Remote Reservoir: Yes
- AAP_UDA_12: EA
- AAP_UDA_22: 1
- AAP_UDA_4: 55
- Add-On Part: 252012 – -4 TO -10 HOSE SHIELD KIT
- Add-On Part: 198000 – 2 PIN COILOVER SPANNER WRENCH KIT
- Add-On Part: 51045 – TOYOTA .25” BUMP STOP SPACER KIT
- Add-On Part: 191003 – ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)
- Add-On Part: 198001 – BILLET SPANNER WRENCH KIT
- Adjustable Damping: NO
- California Prop 65 Warning: Yes
- California Proposition 65: WARNING: This product contains chemicals known to the State of California to cause cancerand birth defects or other reproductive harm.
- Coil Over Springs Included: Yes
- Damping Type: Oil
- Dust Shield: No
- Maximum Lift: 3.5 IN
- Minimum Lift: 0 IN
- OEM Wheels &
- Tires Fitment: Yes
- Recommended Aftermarket Tires: 33″ x 11.50″ (Larger tires may fit but fender trimming and modifications will be required)
- Recommended Aftermarket Wheels: ICON Alloys – 20×9″ w/ 5” Backspace / 0mm Offset
- Recommended Aftermarket Wheels: ICON Alloys – 18×9″ w/ 5” Backspace / 0mm Offset
- Recommended Aftermarket Wheels: ICON Alloys – 17×8.5″ w/ 4.75” Backspace / 0mm Offset
- Service Parts: 191016 – 7.5″ FINNED RESI UPGRADE KIT
- Service Parts: 252001 – 2.5 FIXED SPANNER WRENCH
- Service Parts: 252002 – UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0)
- Service Parts: 254100G – 1 GALLON ICON PERFORMANCE SHOCK OIL
- Service Parts: 257301 – 7/8 SHAFT 10.25 OAL6.00 TRAVEL
- Service Parts: 611019 – COILOVER HARDWARE KIT PAIR
- Service Parts: 611067 – TACOMA/FJ/4RNR LOWER CO BRG/SPCR KIT
- Service Parts: 252003 – SEAL INSTALL TOOL 2.5/3.0
- Shaft Diameter: 0.875 IN
- Spring Color: Black
- Spring Rate Type: Linear
- Title: ICON 2005-2023 Toyota Tacoma 2.5 VS Remote Reservoir Coilover Kit700 lbs/in Coils
Additional Specifications:
- Country of Origin: US
- Weight (lbs): 55.0
- Vehicle Specific Fitment: Y
Instructions
I58730_REVB.pdf
Fitment
: N/A
